[Series EPC] Gastronomy Oven EPC-0511E1
EPC-0511E1: Compact Performance for Professionals
Discover the COMBI OVEN EPC-0511E1, designed to combine performance and functionality in a compact format. With a capacity of 5 GN 1/1 trays, this oven stands out through its flexibility and cutting-edge technology, offering a variety of cooking options: precise baking, gentle steaming, or the perfect combination of both methods.
Thanks to its practical dimensions and advanced features, the EPC-0511E1 is ideal for:
- Small restaurants looking to maximize space efficiency.
- Pastry shops that require uniformity in baking delicate products.
- Developing catering services, where speed and quality are essential.
Its modern design and intuitive technology make this oven an indispensable tool in any professional kitchen. Choose EPC-0511E1 to save time and deliver high-quality dishes, every time.
MODEL | EPC-0511E1 |
TRAY QUANTITY | 5 |
TRAY SIZE (mm) | GN 1/1 |
TRAY SPACING (mm) | 68 |
LOAD PER RACK (Kg) | 18 |
MAXIMUM LOAD (Kg) | 90 |
CHAMBER CAPACITY (L) | 87 |
VOLTAGE | 380-415 Vac (400V nominal) 3ph+N+PE |
SUPPLY FREQUENCY | 50 - 60Hz |
NOMINAL POWER | 8.5 kW at 380 V, 10.1 kW at 415 V |
MAX CURRENT PER PHASE (A) | 16 A |
MINIMUM POWER CABLE SECTION | 5G2.5 mm² (H07RN-F) |
PROTECTION CLASS | IPX4 |
INTERNAL DRAIN PIPE DIAMETER (mm) | 32 |
EXTERNAL EXHAUST PIPE DIAMETER (mm) | 60 |
OPERATING TEMPERATURE RANGE | 30°C - 260°C |
IDEAL INLET WATER PRESSURE | 2-3 bar |
REQUIRED WATER HARDNESS | <8°d (dH) |
WATER CONNECTION | Supply hose with ¾” connection |
PRODUCT DIMENSIONS (mm) W×D×H | 786×870×712 |
PACKAGE DIMENSIONS (mm) W×D×H | 870×970×860 |
NET WEIGHT (Kg) | 95 |
GROSS WEIGHT (Kg) | 128 |
